NEXEN 801656 Clutch Brake Enclosed, Nema C-Faced Clutch-Brake FMCBES-625

NEXEN 801656 Clutch Brake Enclosed, Nema C-Faced Clutch-Brake FMCBES-625

$761.99 USD
$761.99 USD
Sale Sold out

Brand: NEXEN

MPN: 801656

inventory: 003

Country/Region of Manufacture: United States

New in box nexen clutch/brake.
Fast free shipping to the lower 48.





Actuation
Air/Spring
Approximate Brake Facing Life
197 hphr
Approximate Clutch Facing Life
197 hphr
Bore Type
Straight
Brake Facing Edge Color Code
Purple
Brake Facing Type
High Coefficient
Brake Peak Thermal Input Rate
7.00 hp
Clutch Air Chamber Volume When New
1.755 in³
Clutch Air Chamber Volume when Worn Out
2.495 in³
Clutch Facing Edge Color Code
Purple
Clutch Facing Type
High Coefficient
Clutch Peak Thermal Input Rate
7.00 hp
Combination Type
Nema C-Faced Clutch-Brake, Nema C-Faced Clutch-Brake
Combined Continuous Thermal Dissipation
0.14 hp hp
Drive Inertia
6.20 lbin²
Finish
Nickel Plated
Frame Size
56C
Input Shaft Diameter
0.625 in
Manufacturer Product Page
Click here
Manufacturer Upc Number
662284184304
Maximum Pressure
80 psi
Maximum RPM
1800 RPM, 1800 RPM
Maximum Static Brake Torque
142 in, 142 in
Maximum Static Clutch Torque
232 in-lb, 232 in-lb
Open Or Enclosed Design
Enclosed, Enclosed
Output Shaft Diameter
0.625 in
Overhung Load Capacity
92 lb
Port Size
1/8 NPT
Ratings
CE, And RoHS
Restrictions
Consult Nexen For Use In Cyclic Applications
Series
FMCBES, FMCBES
Shaft Inertia
7.10 lb/in²
Temperature Range
32-150 °F
Weight
40.00 lbs
Product Type
Pneumatic Brake & Clutch Assemblies
Bore Type
Straight, Straight
